Feature:
1.Permanent magnet host.
2. Use less electricity to provide more compressed air and gas regulating range.
3. Compared with power frequency air compressor, energy saving is 15%-38%. Compared with ordinary frequency energy saving 5%-10%.
4. System gas fluctuation is bigger, the more obvious energy saving effect.

Specifications：

Model		HS-10AM	HS-15AM	HS-20AM	HS-25AM	HS-30AM	HS-40AM	HS-50AM	HS-60AM
Air delivery(m3/min)/ Work pressure (Mpa)		1.2/0.7	1.65/0.7	2.95/0.7	3.6/0.7	3.86/0.7	5.3/0.7	6.8/0.7	8.2/0.7
		1.1/0.8	1.5/0.8	2.8/0.8	3.2/0.8	3.75/0.8	5.0/0.8	6.5/0.8	7.5/0.8
		0.95/1.0	1.3/1.0	2.65/1.0	3.0/1.0	3.5/1.0	4.5/1.0	5.6/1.0	6.8/1.0
Lube. oil capacity(L)		10	18				30
Noise dB(A)		66±2	62±2						64±2
Drive mode		Belt	Permanent magnet synchronous
Voltage(V/HZ)		380/50
Motor Power		7.5	11	15	18.5	22	30	37	45
Start method		Frequency conversion start
Dimension	Length(mm)	800	1080	1080	1380			1500
	Width(mm)	700	750	750	850			1000
	Height(mm)	930	1000	1000	1160			1330
Weight(kg)		240	450	450	620		680	850
Outlet size (inch)		G½	G¾	DN20	DN25			DN40

Model		HS-75AM	HS-100AM	HS-125AM	HS-150AM	HS-175AM	HS-200AM	HS-250AM	HS-300AM	HS-350AM
Air delivery(m3/min)/ Work pressure (Mpa)		10.9/0.7	14.3/0.7	16.8/0.7	23.6/0.7	25.6/0.7	29.3/0.7	34.2/0.7	42.8/0.7	45.2/0.7
		9.9/0.8	13.3/0.8	15.9/0.8	23.0/0.8	24.8/0.8	28.5/0.8	33.0/0.8	40.0/0.8	43.1/0.8
		9.4/1.0	11.9/1.0	13.9/1.0	19.5/1.0	22.5/1.0	25.6/1.0	30.0/1.0	36.5/1.0	39.3/1.0
Lube. oil capacity(L)		65		72	90		110		125	150
Noise dB(A)		64±2		72±2			74±2	75±2		82±2
Drive mode		Permanent magnet synchronous
Voltage(V/HZ)		380/50
Motor Power		55	75	90	110	132	160	185	220	250
Start method		Frequency conversion start
Dimension	Length(mm)	1900	2000	2000	2500			3150
	Width(mm)	1250	1250	1250	1470			1980
	Height(mm)	1600	1680	1680	1840			2150
Weight(kg)		1800	1900	1960	2700	2900	3200	3500	4000	4500
Outlet size (inch)		DN50		DN50	DN55			DN55
