Electric Piston Air compressor
Feature:

1. Optimized structure and beautiful appearance:
Smooth lines, avant-garde shape design, all parts of a reasonable layout, compact structure;

2. Low noise:
Professional air valve and flow channel design, supporting efficient intake muffler, noise pollution to a minimum;

3. High performance:
Innovative optimization design, precision machining, large displacement, low power consumption;

4. High reliability:
Aluminum cylinder, crankcase, better heat dissipation, low oil temperature and exhaust temperature;
Key parts are precision machined by imported machining center.
Full O-ring seal to prevent oil and gas leakage;
Large capacity gas storage tank can reduce motor starting times and improve motor reliability.

5. Customized motor:
Supporting the development of special motor, starting torque, low temperature rise, long life;

6. Energy saving and environmental protection:
It can meet the requirements of national second-level energy efficiency, save energy and reduce operating costs.

Technical parameters:

Model No.:

LV2008

LV3008

LV4008

LV5508A

LV7508A

LV10008A

Air displacement (m3/min): 0.16 0.24 0.32 0.45 0.63 0.85
Working pressure(Mpa) : 0.8 0.8 0.8 0.8 0.8 0.8
Rotation speed(mm) : 850 1080 1220 1020 1100 1050
Cylinders(mm): 51*2 55*2 65*2 65*3 90*2 90*3
Piston stroke(mm): 46 50 60 60 60 60
Tank(L): 60 90 100 120 170 170
Motor power(kW/Hp) : 1.5/2 2.2/3 3.0/4 4.0/5.5 5.5/7.5 7.5/10
Lubrication Method: Splash Splash Splash Splash Splash Splash
Cooling way : Air cooled Air cooled Air cooled Air cooled Air cooled Air cooled
Driven method : Belt Belt Belt Belt Belt Belt
Weight: 60 70 83 94 120 140
L(mm): 870 980 1070 1210 1290 1400
W(mm): 330 380 380 380 500 520
H(mm): 720 800 840 870 950 1040
